6.5.0-dev (?)

Support for extraction of downloaded archives has been improved. It's now possible to enable support for password-protected archives and for multiple archive formats other than .7z such as .zip. This can also be used to lower the memory requirements for extraction of .7z archives that contain large files. Additionally the [Files] section now supports archive extraction.

All of this is optional and does not increase the size of Setup if not used.

• Updated [Setup] and [Files] section:
  • Added new [Setup] section directive ArchiveExtraction to specify the method of archive extraction used by new [Files] section flag extractarchive (see below) and support functions ExtractArchive and CreateExtractionPage:
    • basic (default) is the method introduced by Inno Setup 6.4.0. It only supports .7z archives that are not password-protected.
    • enhanced/nopassword is a new method and internally uses 7zxr.dll from the 7-Zip source code by Igor Pavlov, as-is, except that it was recompiled, code-signed, and renamed to is7zxr.dll. Compared to basic, it has lower memory requirements for archives that contain large files but increases the size of the Setup file(s). It still only supports .7z archives that are not password-protected.
    • enhanced uses 7zxa.dll instead of 7zxr.dll, recompiled, code-signed, and renamed to is7zxa.dll. It still only supports .7z archives, but they may be password-protected.
    • full uses 7z.dll instead of 7zxa.dll, recompiled, code-signed, and renamed to is7z.dll. It supports multiple archive formats (.7z, .zip, .rar, and more), although not as many as the original 7z.dll, to reduce its size.
    New documentation topic ArchiveExtraction has a table summarizing the differences between these methods.
  • Added new [Files] section flag extractarchive and parameter ExtractArchivePassword, intended to enable the seamless integration and extraction of archives.
    • The supported archive formats, beyond .7z, and the support for password-protected archives, depend on the aforementioned ArchiveExtraction directive, that must not be set to basic.
    • Flag extractarchive must be combined with the external and ignoreversion flags. It is usually also combined with the recursesubdirs and createallsubdirs flags.
    • Using a solid archive is not recommended; extraction performance may degrade depending on the solid block size.
    • Archive extraction otherwise behaves the same as external file copying. For example, it supports automatic uninstallation of extracted files and can be combined with same other flags and parameters.
    • Example script:

      [Setup]
      ArchiveExtraction=enhanced/nopassword

      [Files]
      Source: "{tmp}\MyProg-ExtraReadmes.7z"; DestDir: "{app}"; \
        Flags: external extractarchive recursesubdirs createallsubdirs ignoreversion

  • Updated example script CodeDownloadFiles.iss to demonstrate how to use a single [Files] entry to extract a downloaded archive.
  • Archive extraction now honors the file system redirection state set by 64-bit install mode, entry flags, and support function EnableFsRedirection.
• Updated Pascal Scripting:
  • New support function ExtractArchive replaces the deprecated Extract7ZipArchive. ExtractArchive includes an additional parameter to optionally specify a password.
  • ExtractArchive and CreateExtractionPage now overwrite read-only files which already exist in the destination directory without prompting the user. Previously this would cause an extraction error.
  • Added new AddEx function to support class TExtractionWizardPage to add password-protected archives.

Support for downloading files has been improved: the [Files] section now supports file downloads. Writing Pascal Script to download a file is no longer necessary and is in fact less efficient since it requires an intermediate temporary file which this new download support doesn't.

• Updated [Files] section:
  • Added new [Files] section flag download and parameters DownloadUserName and DownloadPassword, intended to enable the seamless integration of downloaded files.
  • Supports HTTPS (but not expired or self-signed certificates) and HTTP. Redirects are automatically followed and proxy settings are automatically used. Safe to use from services.
  • Flag download must be combined with the external and ignoreversion flags. Additionally, the DestName and ExternalSize parameters must be set.
    It can also be combined with the new issigverify flag (see below) for efficient and highly secure verification of the download file.
    It cannot be combined with the comparetimestampalso, recursesubdirs and skipifsourcedoesntexist flags.
  • File download otherwise behaves the same as external file copying. For example, it supports automatic uninstallation of downloaded files and can be combined with same other flags and parameters.
  • Example script:

    [Files]
    Source: "https://jrsoftware.org/download.php/is.exe?dontcount=1"; DestName: "innosetup-latest.exe"; DestDir: "{app}"; \
      ExternalSize: 7_000_000; Flags: external download ignoreversion

  • Updated example script CodeDownloadFiles.iss to demonstrate how to use a single [Files] entry to download a file.

Inno Setup now includes an integrated signature-verification capability that can be used to detect corruption or tampering in your files at compile time, before files are included in an installer being built, or during installation, before Setup copies external files onto a user's system.

Any type of file may be signed and verified, and creation of signatures does not require a certificate from a certificate authority. There is no cost involved.

Note, however, that these signatures cannot be used to eliminate an "Unknown publisher" warning message shown by Windows when an installer or other EXE file is started. That requires a completely different kind of signature (Authenticode) embedded inside the EXE file by a different tool (Microsoft's signtool.exe), and it does require a (usually expensive) code-signing certificate from a certificate authority.

A more detailed summary:

• New [ISSigKeys] section:
  • Added a new optional [ISSigKeys] section for defining keys used by the compiler and Setup to verify file signatures.
  • Supports parameters Name (required) and Group to identify keys, parameters KeyFile, PublicX, and PublicY to specify the key values, parameter KeyID to double-check the key values, and parameter RuntimeID for runtime identification of the key.
  • Key files are human-readable and can be created using Inno Setup Signature Tool (see below).
  • Example section:

    [ISSigKeys]
    Name: anna: KeyFile: "anna.ispublickey"; Group: exesigner
    Name: ryan; KeyFile: "ryan.ispublickey"; Group: exesigner
    Name: ivan; KeyFile: "ivan.ispublickey"; Group: docsigner
    ; max is trusted for both exe and doc signing
    Name: max; KeyFile: "max.ispublickey"; Group: exesigner docsigner
    ; the boss also has a key
    Name: bosskey; KeyFile: "boss.ispublickey"

• Updated [Files] section:
  • Added a new issigverify flag for enforcing cryptographic signature verification of source files using a key from the [ISSigKeys] section, enhancing security during both compilation and installation.
  • When used without the external flag, verification is performed during compilation, aborting if it fails. When used with the external flag, verification occurs during installation, ensuring the integrity of files as they are copied.
  • Requires an .issig signature file to be present in the same directory as the source file. Signature files are human-readable files and can be created using the Inno Setup Signature Tool.
  • Has little performance impact since verification occurs while source files are being compressed/copied and each file's contents are only read once; the only extra I/O comes from reading the tiny .issig files. Only archives and downloaded files are read a second time.
  • The verification process is protected against the Time-Of-Check to Time-Of-Use (TOCTOU) problem.
  • Can be used to verify downloaded files, offering flexibility over SHA-256 checks as script changes aren't needed for file updates. See the updated CodeDownloadFiles.iss example script for an example.
  • Added a new and optional ISSigAllowedKeys parameter to restrict which keys or groups of keys from the [ISSigKeys] section are permitted for signature verification using the issigverify flag.
  • Note: The issigverify flag cannot be combined with the sign or signonce flags. Use signcheck instead.
  • Example section:

    [Files]
    Source: "MyProg.exe"; DestDir: "{app}"; \
      ISSigAllowedKeys: "exesigner bosskey"; Flags: issigverify
    Source: "MyProg.chm"; DestDir: "{app}"; \
      ISSigAllowedKeys: "docsigner bosskey"; Flags: issigverify
    Source: "{src}\Extra\*.chm"; DestDir: "{app}"; \
      ISSigAllowedKeys: "docsigner bosskey"; Flags: issigverify external; \
      Excludes: "*.issig"
    Source: "https://jrsoftware.org/download.php/is.exe?dontcount=1"; DestDir: "{app}"; \
      ISSigAllowedKeys: "exesigner bosskey"; Flags: issigverify external download ignoreversion; \
      DestName: "innosetup-latest.exe"; ExternalSize: 7_000_000

• New Inno Setup Signature Tool:
  • Added ISSigTool.exe, a new command-line utility designed to sign files using ECDSA P-256 cryptographic signatures.
  • Offers commands to sign and verify files, to export public keys and to generate private keys.
  • Example commands:

    issigtool --key-file="MyKey.isprivatekey" generate-private-key
    issigtool --key-file="MyKey.isprivatekey" sign "MyProg.dll"
    issigtool --key-file="MyKey.isprivatekey" export-public-key "MyKey.ispublickey"
    issigtool --key-file="MyKey.ispublickey" verify "MyProg.dll"

• Updated documentation:
  • Added new [ISSigKeys] section topic.
  • Updated [Files] section topic.
  • Added new .issig Signatures: Introduction topic.
  • Added new Inno Setup Signature Tool topic.
• Other related changes:
  • The compiler now verifies that precompiled files like SetupLdr.e32 and Setup.e32 remain unchanged before using them. Can be disabled using new [Setup] section directive VerifyPrecompiledFiles. Doing so is not recommended.
  • Added new [Files] section parameter Hash. Instructs the compiler or Setup to do a simple SHA-256 hash check instead of a full signature verification, as an alternative to using the issigverify flag.
    Example script:

    [Files]
    Source: "https://jrsoftware.org/download.php/iscrypt.dll?dontcount=1"; DestName: "ISCrypt.dll"; DestDir: "{app}"; \
      Hash: "2f6294f9aa09f59a574b5dcd33be54e16b39377984f3d5658cda44950fa0f8fc"; \
      ExternalSize: 2560; Flags: external download ignoreversion

  • Pascal Scripting:
    • Added new ISSigVerify and DownloadTemporaryFileWithISSigVerify support functions.
    • Added new AddWithISSigVerify and AddExWithISSigVerify functions to support class TDownloadWizardPage. See updated example script CodeDownloadFiles.iss for an example.

• Compiler IDE:
  • The Find in Files result list will now update its line numbers when you add or delete lines.
  • The Highlight occurrences of current word option (which is disabled by default) no longer highlights a section's directive names, parameter names, or Pascal keywords. The Highlight occurrences of current selection option (which is enabled by default) still does.
• [Files] section parameter Excludes can now be combined with the external flag.
• Parameters ExternalSize, ExtraDiskSpaceRequired, and UninstallDisplaySize now support digit separators. Example: UninstallDisplaySize=1_073_741_824.
  The same applies to [Registry] parameter ValueData if ValueType is set to qword.
• ISPP changes:
  • Added predefined variable __DIR__. Returns the directory of the current include file.
  • Renamed predefined variables __FILE__ to __FILENAME__ and ISPPCC_INVOKED to ISCC_INVOKED. The old names still work.
  • Renamed support function RemoveBackslash to RemoveBackslashUnlessRoot. The old name still works.
  • Fix: The return value of support function ExtractFilePath did not always include a trailing backslash as intended.
• Pascal Scripting change: Added new GetSHA256OfStream support function.
• Inno Setup 6.4.3 increased the maximum width of all task dialogs by about 50%, which helps to keep long paths from being truncated with ellipses. It now only does this if the task dialog's content actually contains a path.
• All translations which still had an UTF-8 BOM had their BOM removed. Using a BOM in UTF-8 encoded files is not needed and not recommended since Inno Setup 6.3.0.
• Inno Setup is now built using Delphi 12.3 Athens instead of Delphi 12.1 Athens. Thanks to Ian Barker from Embarcadero for providing us with a license!
• Documentation improvements.
• Minor tweaks.

Some messages have been removed and added in this version: (View differences in Default.isl.)

• Removed messages:
  • ErrorFileHash1, ErrorFileHash2.
• New messages:
  • ArchiveIncorrectPassword, ArchiveIsCorrupted, ArchiveUnsupportedFormat.
  • StatusDownloadFiles.
  • SourceVerificationFailed, VerificationSignatureDoesntExist, VerificationSignatureInvalid, VerificationKeyNotFound, VerificationFileSizeIncorrect, VerificationFileHashIncorrect.
  • ErrorDownloading, ErrorExtracting.

Note: Not all official translations have been updated for these changes yet.

Inno Setup 6.4 Revision History
